The GOKU GM10 V3 GPS series! With the latest M10050 GNSS chip, it offers ultra-accurate positioning and faster star search speeds than the previous GM8 V2.
The GOKU GM10 Nano V3 GPS with compass is designed for convenience, featuring a plug-and-play setup without the need for soldering.
Experience cutting-edge technology for precise navigation. Whether you're an outdoor enthusiast or a professional, GOKU ensures reliability, accuracy, and effortless usability. Upgrade to the GOKU GM10 V3 GPS series and elevate your navigation experience.
Description
Brand: FLYWOO
Model: GM10 NANO V3 GPS w/compass
Dimension :12mm*17mm*5mm
Weight : 2.6g
Connector : 4pins Pad
Features:
1、GPS Module. Three Modules.
2、4pins Pad, ultra light weight
3、With a compass and a plug.
4、Plug and play, no need for soldering.
Specification
Electrical Characteristics
Chipset : M10050(Tenth Generation Chip)
Receiving Format : GPS,GLONASS,Galileo,BeiDou,QZSS and SBAS
Default Protocol : GPS,Galileo,BeiDou
Frequency : GPS L1,GLONASS L1,BeiDou B1,SBAS L1,Galileo E1
Channels : 72 Searching Channel
Sensitivity
Tracking : -162dBm
Reacquisition : -160dBm
Data and Update Rate
Support Rate : 4800bps to 921600bps,Default 115200bps
Data Level : TTL or RS-232,Default TTL level
Data Protocol : BF4.3.X(UBLOX)/BF4.2.X(NMEA)
Output frequency : 1Hz-10Hz,Default 10Hz
Operational Limits
Altitude : 50,000m Max
Velocity : 500m/s Max
Acceleration : Less than 4g
Power consumption
VCC : DC Voltage :3.3-5V
Operating temp : -40 °C ~ +85°C
Storage Temp : -40°C ~ +105°C
Indicator :
PPS LED: Yellow. PPS LED not bright when GPS not fixed, flashing when fixed.
The Module’s Pins: RX TX 3.3-5V GND
Includes
1x GM10 NANO V3 GPS w/compass
1x 100mm Cable
1x Copper Foil
